Defibrillator BeneHeart D6

The bed and telescopic pedestal table made of stainless steel. The upper part (the bed) rentgenprozrachnaya table consists of a section for the head of the central section (seating section), Cities for renal (kidney roller), back section and two sections for the legs. Double top panel of the operating table makes it possible to do it the X-rays.

The mattress is made of PU-material which ensures hygienic quality and easy to clean after use. The wheels ensure easy movement of the table within the operating room, and lock the support legs of the table and reliable stability. Availability bridge renal (kidney roller) embedded in the basic design of the table, to facilitate manipulation of the patient during surgery on the kidney.

The all-mechanical design work on this table can not affect the sudden termination of power, so it is very safe and reliable.

This ideal operating table with a wide range of possible applications, easy to use, convenient when setting, is reliable to use and stable operating characteristics.

Features MT300 settings:

table height adjustment takes place by means of a hydraulic drive pedal.

Tilt the bed to position trendeleburg and reverse Trendelenburg tilts the bed of the left and right sections of the slopes back and leg sections is done by manual drive.

The slope section of the head are made via pnevmpruzhiny.

Adjusting the height of the bridge to the kidneys (renal roller) are carried out mechanically by rotating the corresponding knob.

Provision of support for the hands, legs under the knees, side supports, abutments shoulder configured manually.

Dimensions upper part

table (L × W):

 2010 × 500 mm

 The height of the table top

floor:

 790-1040 mm

The range of movement up and down

250 mm

Trendelenburg

25 °

Reverse Trendelenburg

25 °

Lateral tilt left bed

20

Lateral tilt right bed

20

The slope of the section for a head-up

thirty

The slope of the section for the head down

90 °

The slope of the foot section down

90 °

The slope of the dorsal section up

90 °

The slope of the dorsal section down

10

Bridge to the kidneys (renal roller)

0-120 mm

The maximum safe load

160 kg

Gross Weight,

255 kg

Net Weight,

205 kg.

Cardiomonitor Heaco G3D - is a device for continuous monitoring of cardiac function and the alarm when rhythm disturbances.

12.1 inch color display shows the following physiological parameters as standard: ECG; NIBP (non-invasive blood pressure), SpO2 (oxygen saturation), PR (pulse rate), RESP (respiration), TEMP (temperature). If necessary, the heart monitor can be equipped with a module for measuring invasive blood pressure, perfusion index, and CO2. The data are displayed as curves in the left area and the right-hand numerical values.

Connectors for sensors located on the front, which is very convenient in use. In the middle top of the monitor in the form of a heart is light alarms. Alarms are produced both in color and in sound broadcasting. G3D can store about 24 hours indicators. Heart monitor can work not only from the mains but also from the battery. To create maximum comfort and calm the patient can completely disable the sound pulse. For complete control of the heart, this unit records and stores the last 60 of arrhythmia events.

For convenience, provided a mobile stand and a special wall mount.

1. Monitor the patient;

2. Network cable;

3. The cuff;

4. Extension of the cuff;

5. ECG cable;

6. Disposable ECG electrodes - 10 pcs .;

7. SpO2 sensor;

8. Nasal breathing tube (disposable);

9. A temperature sensor (rectal and dermal);

10. The earthing cable;

11. The fabric cover for dust protection - 2 pcs .;

12. Instructions;

13. Warranty Card;

14. A copy of the registration certificate of the Ministry of Health of Ukraine;

15. A copy of the Certificate of Compliance UkrSEPRO.

monitor Attributes

Monitor Type Ward

Series G

Screen size 12.1 "

Number of trends on the screen 8

There ECG

Non-invasive blood pressure There

HR Any

The temperature is

Capnography (CO2) There

Saturation (SPO2) There

Respiratory rate there

Invasive blood pressure There

Multigaz (AG) No

Cardiac output No

The depth of anesthesia No

Yes Built-in printer

Combining a central station Yes

Warranty 18 months

Characteristic features of the ultrasound system:

▪ 15-inch LCD Monitor

▪ The main imaging modes: B, M, PW, HPRF, Color Doppler, power Doppler, harmonic with a phase shift

▪ iScape / iZoom / iBeam / iClear / iTouch

▪ Advanced scanning angle through ExFov function

▪ Hard Drive: 320 GB;

▪ Built-in rechargeable battery

▪ 2 ports for connecting ultrasonic sensors

▪ Weight: approximately 8 kg.

Control Panel:

▪ High contrast 15 "LCD Monitor

▪ Modes images W / O / PW / HPRF /

▪ tissue (THI), and phase inversion Tissue Harmonic Imaging (PSHI)

▪ 8-tier compensation depth gain (TCG)

▪ Simultaneous connection of two sensors

▪ 4 x USB-port

▪ iClear (clear image)

▪ iBeam (increasing the spatial resolution)

▪ iZoom (zoom with detail preservation)

▪ iTouch (avtooptimizatsiya)

▪ bStreer (maneuvering beam for better visualization)

▪ iStation (research data archive)

Resolution:

▪ Automatic calculation of the intima / media

▪ panorama scan (iScape View)

Sensors:

▪ Linear Sensor 5-10 MHz, 40 mm, D11,2 cm (75L38EA)

▪ Linear Sensor 5-10 MHz, 24 mm, D11,2 cm (10L24EA)

▪ Convex probe 2-6 MHz, R50, D30,2 cm (35C50EA)

▪ microconvex probe 5-8.5 MHz, R15, D11,2 cm (65C15EA)

▪ Endokavitalny probe 5-8.5 MHz, D11,9 cm (65EC10EA)

▪ microconvex 2-5 MHz transducer, R20, D30,2 cm (35C20EA)

Attachment to the sensors:

▪ Reusable biopsy steel nozzle for 35C50EA sensor, 65C15EA, 65EC10EA, 65EC10ED, 65EB10EA

▪ Reusable biopsy steel nozzle with a removable needle guide for 35C50EA sensor, 35C20EA, 75L53EA, 10L24EA, 65EL60EA, 75LT38EA

▪ Reusable plastic biopsy guide attachment with detachable needles 75L53EA sensor

Accessories:

▪ Mobile stand UMT-160

▪ Mobile stand UMT-150

▪ Carrying Case

▪ External DWD-RW

▪ video printer SONY UP897MD

▪ video printer MITSUBISHI P93W

▪ Water-resistant footswitch on the pedal 1

▪ Water-resistant footswitch 2 pedals

▪ Water-resistant footswitch 3 pedals

Standard equipment:

1. Main Unit;

2. The power cord;

3. Gel for ultrasound;

4. Invoice circuit controls (sticker on the keyboard);

5. The sensor holder;

6. Ground cable;

7. Remote video printer line;

8. Instructions;

9. Warranty Card;

10. A copy of the registration certificate of the Ministry of Health of Ukraine;

11. A copy of the Certificate of Compliance UkrSEPRO.

Attributes SPL station

Screen 15 "

Warranty 18 months

Scanning

W / O Yes

Color Doppler mapping Yes

Color M-Mode Yes

Yes Energy

Directed energy None

PW Yes

Pulsed flows for high speeds Yes

Permanent Wave No

cloth No

Vizualiztsiya

Anatomical M-mode No

Panoramic scan Yes

Keystone Yes

No 3D reconstruction

Tissue harmonic None

Inversion Tissue Harmonic Yes

The envelope anatomical M-mode No

No Elastography

Number of ports for sensors 2

4 USB ports

DVD-RW Yes

S-Vedio / VGA Yes

Internal memory, GB 320

ECG module and PCG No

No ECG Visualization

Technologies

iClear Yes

Yes iBeam

Yes iZoom

Yes iTouch

iPower Yes

No HR Flow

Yes iStation

No iWorks

The main program

Package standard calculations Yes

Advanced calculations in the direction Yes

Calculation intema / Media Yes

No Stress Echo

Sensors

Linear Yes

Convex Yes

Yes microconvex

Yes Endokavitalny

No surround Endokavitalny

No Biplanovy endorectal

phase No

Surround No

Pencil No

Esophageal No

Intraoperative No

Shadowless operating light in which the light source used tungsten-halogen lamps, is characterized by high brightness, low heat radiation, excellent color reproduction in combination with modern built-balancing system and long service life.

The design of the luminaire provides a large range of applications. The above advantages have made light convenient for use in hospitals and clinics.

Shadowless effect is achieved through the use of multiple svetoolticheskih elements. Closed luminaire housing design makes it possible to fully satisfy the requirements for surgical sterility and safety. focus mechanism easy to use.

Number of reflectors

12

light

80000-140000 lux (4-speed Light Control)

Colorful temperature

 4500 + 500 K

The range of the light field regulation

100-200 mm

power Options

220 + 10%, + 1Hz 50

Rated voltage lamps

24

Nominal lamp power

25 W

power consumption

400W

The diameter of the lamp housing

900 mm

Net weight

65 kg

Gross weight

123 kg

Dimensions of packaging

housing

114h114h38,5 cm

Bracket

 96h40h34 cm

(Increased warranty period to 24 months, except for the battery and consumables)

Aspiration Medical Model 7E-D - is a modern portable medical suction device, which can operate on three types of power sources: AC, DC and battery.

It is designed to provide emergency care to patients with blocked airways in the hospital environment, ambulances, home and health care services. This device is capable of removing secretions, blood, vomit, which block the airway smooth to resume breathing, particularly useful for providing first aid and treatment of patients during transport and in places where there is no AC or DC power.

Oil-free piston vacuum pump operates without the use of steam and lubricants

Low noise level

The floating device prevents the liquid from entering the pump

Vacuum suction may be adjusted depending upon the particular application

Small size and light weight of the device makes it convenient to carry

Fully plastic outer casing provides excellent protection against corrosion and easy to clean.

Maximum vacuum

0.08 MPa (680mm.rt.st.)

The range of vacuum regulation

0-0,08 M ​​Pa (0-680 mm Hg)

Maximum flow: air

liquid

 ≥ 20 l / min.

zhidkost≥ 6 l / min

sound level

 <65 dB (A)

The capacity for absorption of

1000 ml

Power Supply:

220 ~ + 10%, 50 Hz; 12

Power

44 VA

Weight:

6.0 kg

Dimensions:

280h192h285 mm

Characteristic features of the ultrasound system:

▪ 15 "LCD liquid crystal display;

▪ i-Station - platform intelligent management information base of patients;

▪ i-Touch - automatic image optimization;

▪ iBeam - spatial composite image;

▪ Smart3D - three-dimensional image reconstruction unit (optional);

▪ iScape View - panoramic display module (optional);

▪ iClear - fynktsiya cleaning, reducing graininess

▪ Operating modes: 2D, M, PW (pulsed wave Doppler)

▪ CW (constant wave Doppler) (optional), HPRF (Doppler at high flow rates)

▪ Color (color Doppler)

▪ Power (energy Doppler)

▪ DirPower (directional Doppler);

▪ THI - technology of THI

▪ The panoramic display (optional);

▪ Built-in battery, two USB ports;

▪ Multilanguage support (8 languages);

▪ Multifrequency sensors (2-12 MHz) 2-12 MHz

▪ Built-in battery for continuous operation;

▪ ECG module (optional);

▪ Weight: 6 kg

 Control Panel:

▪ 15 "LCD LCD Monitor

▪ M5 main platform (Windows)

▪ Formation of Tissue Harmonic Imaging

▪ iBeam - Spatial composite image

▪ iTouch - Automatic image optimization

▪ Pulsed wave Doppler

▪ Color / Power / directional power Doppler

▪ Hard disk 160 GB

▪ S-video output and two USB ports

▪ Measuring and computational software packages

Additionally

1. Extensions:

▪ Automatic calculation of the intima / media

▪ panorama scan (iScape View)

▪ Anatomical M-mode

▪ Three-dimensional reconstruction method of "free hand" (Smart 3D)

2. Sensors:

▪ Convex probe 2,5 / 5,5 / H5,0 / H6,0 MHz (3S5s)

▪ Linear Sensor 5.0 / 7.5 / 10.0 MHz, 35 mm (7L4s)

▪ Endokavitalny microconvex sensor 5.0 / 6.5 / 8.0 MHz (6SV1s)

▪ Linear Sensor 5.0 / 7.5 / 10.0 MHz, 56 mm (7L6s)

▪ Linear Sensor 5.0 / 7.5 / 10.0 MHz, 52 mm (7L5s)

▪ Linear Sensor 8.0 / 10.0 / 12,0MGts, 35 mm (10L4s)

▪ Linear Sensor 8,0 / 10,0 / 25 mm 12,0MGts (L14-6s)

▪ sensor microconvex 5.0 / 6.5 / 8.0 MHz (6S2s)

▪ microconvex sensor 2,5 / 3,5 / 5,0 / H5,0 / H6,0 MHz (3S1s)

▪ phased sectoral sensor 2,0 / 2,5 / 3,0 / H3,5 / H4,0 MHz (2P2s)

▪ Intraoperative Linear T-shaped sensor is 5.0 / 7.5 / 10.0 MHz (7LT4s)

▪ endorectal linear probe 5.0 / 6.5 / 8.0 MHz (6LE7s)

▪ Biplanovy endorectal probe 5.0 / 6.5 / 8.0 MHz (6LB7s) (required to operate a special port)

3. Attachment to the sensors:

▪ Reusable steel nozzle for biopsy probe

▪ Reusable biopsy steel nozzle with a removable needle guide sensor

▪ Reusable plastic biopsy guide attachment with a removable needle probe

4. Accessories:

▪ Mobile stand UMT-200

▪ Carrying Case

▪ External DWD-RW

▪ video printer SONY UP897MD

▪ video printer MITSUBISHI P93W

▪ Water-resistant footswitch 2 pedals

▪ Extender ports for sensor 3 (PEM-11)

▪ A set of belts to be scanned standing

▪ docking stations, USB, COM, LPT, VGA, microphone, audio, composite video iDOCK

▪ Module to output audio / video signal

▪ Adapter for wireless iROAM

▪ AC adapter and battery (4500mAh)

Standard equipment:

1. Main Unit;

2. The power adapter and connecting cable;

3. Gel for ultrasound;

4. Rechargeable batteries - 2 pcs .;

5. Invoice circuit controls (sticker on the keyboard);

6. Case on wheels;

7. Dust Mesh - 2 pcs .;

8. Cover for closing the connector - -2 pcs .;

9. Instructions;

10. Warranty Card;

11. A copy of the registration certificate of the Ministry of Health of Ukraine;

12. A copy of the Certificate of Compliance UkrSEPRO.

Attributes SPL station

Screen 15 "

Warranty 18 months

Scanning

W / O Yes

Color Doppler mapping Yes

Color M-Mode Yes

Yes Energy

Directed energy Yes

PW Yes

Pulsed flows for high speeds Yes

Permanent-wave Yes

cloth No

Vizualiztsiya

Anatomical M-Mode Yes

Panoramic scan Yes

Keystone Yes

3D reconstruction Yes

Tissue harmonic None

Inversion Tissue Harmonic Yes

The envelope anatomical M-mode No

No Elastography

Number of ports for sensors 1, 2

2 USB ports

DVD-RW Yes

S-Vedio / VGA No

Internal memory, GB 320

ECG module and PCG Yes

Visualization ECG Yes

Technologies

iClear Yes

Yes iBeam

Yes iZoom

Yes iTouch

iPower Yes

No HR Flow

Yes iStation

No iWorks

The main program

Package standard calculations Yes

Advanced calculations in the direction Yes

Calculation intema / Media Yes

No Stress Echo

Sensors

Linear Yes

Convex Yes

Yes microconvex

Yes Endokavitalny

No surround Endokavitalny

Biplanovy endorectal Yes

phase Yes

Surround Yes

Pencil No

Esophageal No

Intraoperative Yes

Cardiograph Heaco 100G - a 12-channel portable and easy to use device, which is popular among cardiologists and internists. It is an indispensable tool for the diagnosis of the condition of the heart in patients ambulance.

Cardiograph 100G logs twelve-lead with the opportunity to preview and then print ECG on thermal paper. Cardiograph cardiology and displays the heart rate on the touchscreen color display, it allows you to record clear ECG curve thanks to an improved filter system from interference.

Cardiograph Heaco 100G is a lightweight (500 g) and has larger dimensions (mm 199h96h61). Can record on SD card up to 100 surveys.

Heaco 100G includes:

- Built-in thermal printer for printing 12-lead;

- Touch screen monitors 3/12 channels simultaneously;

- Built-in battery that supports over 4 hours of continuous printing, with the possibility of recharging;

- Connect to a PC via a USB 2.0 port;

- Transfer to the USB-flash drive and store surveys on the SD card.

1. ECG machine;

2. ECG cable (10 branches);

3. Paper (50x200 mm);

4. Network cable;

5. The power supply;

6. Gruszka electrode 6 pcs .;

7. clothespin electrode 4 pcs .;

8. Ground cable;

9. Software CD;

10. SD card;

11. Bag (depending on supply);

12. Instructions;

13. Warranty Card;

14. A copy of the registration certificate of the Ministry of Health;

15. A copy of the UkrSEPRO.

ECG Attributes

Type kandiografa Portable

Screen Type Color touch

Screen Size 2.5 "

Number of ECG channels 3/12

The screen display 12 channels

Simultaneous printing (channels) 3

Synchro Recording

Paper width 50 mm

Connecting to a PC Standard features

There Avtodiagnoz

There are auto-sensing

Automatic Print Speed: 25 mm / sec, 50 mm / sec. Recording mode: 25 mm / sec, 50 mm / sec. Manual mode: 5 mm / s 6.25 mm / s, 10 mm / 12.5 mm / s 50 mm / s.

Warranty 12 months

(Increased warranty period to 24 months, except for the battery and consumables)

Patient Monitor "BIOMED" iM 15 is designed for use in intensive care, neonatal wards, intensive care units, operating rooms and other medical facilities, and emergency services.

Features:

Multifunctional patient monitor with touch screen 15-inch high resolution color TFT-LCD.

The patented measurement technology NІAT: temperature drift suppression.

Intuitive interface with large font.

Signals, lights, alert a human voice.

Controls: ECG signal, respiration, oxygen saturation of arterial blood (the SpO2), temperature 2 channels, NІAT, heart rate, IAT 2-channel (optional), capnography 2-channel (EtSO2) (optional), the degree of the depth of anesthesia (optional) , multigaz (optional).

Analysis arrhythmia and ST-segment in real time, determining pacemaker.

Printing on the built-in thermal printer up to three channels (paper width 48 mm).

Memory: 720 hours of graphic and digital trends in all respects, 1000 NIAT.

The number of waveforms on the screen: Up to 10 curves.

Ability to connect to a central monitoring station.

Power: continuous operation AC and up to 4 hours of battery life.

An electrocardiogram (ECG):

Challenge: I, II, III, aVR, aVL, aVF, V; or I, II, III, (optional); or I, II, III, aVR, aVL, aVF, V1-V6 (Optional)

Sensitivity: 1.25 mm / mV, 2.5 mm / mV, 5.0 mm / mV, 10.0 mm / mV, 20.0 mm / mV, 40.0 mm / mV AUTO.

Scanning speed: 6.25 mm / 5.12 mm / 25.0 mm / 50.0 mm / s;

Respiration (RESP):

Measurement range: Adult: 0 stomach / min - 120 gut / min. Children: 0 stomach / min - 150 gut / min. Newborns: 0 stomach / min - 150 gut / min

Resolution 1 stomach / min

Accuracy: ± 2%.

Pulse oximetry (SpO2):

Measuring range: 0-100%

Resolution: 1%

Accuracy at 70-100%: ± 2%

Pulse rate: 25-250 beats / min

Accuracy ± 3 beats / min or ± 1%, whichever is greater

Temperature (TEMP):

Measurement range: 0-50 ° C

Resolution: ± 0,1 ° C

Accuracy: ± 0,1 ° C

NIAT (NIBP):

Measurement method: Automatic ostsilometriya

Measuring modes: manual, automatic, continuous

Pressure measuring range:

Adults: 10-270 mmHg

Children: 10-200 mmHg

Newborns: 10-135 mmHg

Resolution ± 3 mm Hg

thermal:

Paper width: 50 mm.

Thermal Paper Speed: 12.5 mm / s; 25.0 mm / s; 50.0 mm / s.

Printing: maximum 3 channels (curves).

IAT (IBP), option:

Channels: 2 channels

Measurement Range: -50-350 mm

Accuracy: ± 2%

Capnography (EtSO2) option:

Measuring range: 0% -13%

Resolution 1 mm

Breathing: 3-150 stomach / min

The degree of depth of anesthesia (CSM), option:

CSI: EEG signal attenuation factor> 140 dB; depth of anesthesia index 0 - 100; BS0% - 100%; EEG sensitivity ± 400 mV; EMG (EMG) 0 - 100.

IoC: EEG signal attenuation factor> 100 dB; depth of anesthesia index 0 - 100; BS 0% - 100%; EEG sensitivity ± 475 mV; EMG (EMG) 0 - 100.

Multigaz (AG), option:

CO2: 0-25%

N2O: 0-100

Desflurane: 0-25%

Sevoflurane: 0-25%

Enflurane, Isoflurane, halothane 0-5%

AwRR: 3-100 stomach / min

O2: 0-100%

Equipment:

Name

amount

The main unit 15 iM (touchscreen)

1 PC.

ECG cable 5-taps

1 PC.

Sensor SpO2 (adult)

1 PC.

Temperature sensor for adults, epidermal, multiple

1 PC.

Temperature sensor for adults, rectal, multiple

1 PC.

Battery

1 PC.

NIBP cuff for adults

1 PC.

tube NIBP

1 PC.

Disposable electrodes (adults)

10 pcs. / 1 ​​set

Power cable

1 PC.

Thermal

1 PC.

potential equalization wire

1 PC.

User's manual

1 copy

G6B + - is a modern fetal monitor to check the fetus and the mother. It is used to diagnose the parameters for antenatal examination, during delivery and pre-natal ward.

The monitor consists of a central unit and the relevant functional applications. There may be complete without the control and supervision of the mother. Options monitor wireless sensors provides a comfortable use of the device at a distance from the patient.

You can select the configuration of your choice and depending on the needs.

G6B designed to monitor the status of the fetus and is equipped with multiple functions: measuring fetal heart rate (both have two fetuses), tokometriya (uterine contractions) and mobility. G6B + mother's control measures ECG, the SpO2, blood pressure, heart rate and temperature.

Its 12.1 inch color screen displays curves, waveforms and data. Monitor screen can be divided into three areas: the area of ​​channels, range of parameters and status bar. Status information is displayed at the top and bottom of the screen. Channel region disposed on the left side of the screen, while the output parameters themselves the right side. Built-in thermal printer can print real-time data on the status of the fetus.

When the vital signs of the patient become pathological, or in the event of a monitor mechanical or electrical problems, monitor, audible or visual alarms to notify medical personnel.

This monitor allows events to determine denote specific situations, such as receiving a dose of medicament and has a calculator of drugs that can calculate unknown values ​​using the available data that will help to control the administration of drugs.

Fetal Monitor Heaco G6B + can operate on battery power in the absence of a network of more than 8 hours and store data on the trend of 24 hours.

Measuring range:

TOKO 0 - 100 units .;

Heart rate 10 - 300 beats / min .;

SpO2 0 - 100%;

PP mother of 30 - 250 beats / min.

Modification of control without a mother:

1. Fetal Monitor;

2. Network cable;

3. FHR transducer (for monitoring fetal heart rate) - 2 pcs .;

4. Sensor TOKO (monitoring of uterine tone and fetal movement);

5. Event Marker;

6. Belt Sensor fixing - 3 pcs .;

7. Paper;

8. The fabric cover;

9. Instructions;

10. Warranty Card;

11. A copy of the registration certificate of the Ministry of Health of Ukraine;

12. A copy of the Certificate of Compliance UkrSEPRO.

Modification with the mother's control:

1. Fetal Monitor;

2. Network cable;

3. FHR transducer (for monitoring fetal heart rate) - 2 pcs .;

4. Sensor TOKO (to control the tone of the uterus and fetal movement;

5. Event Marker;

6. Belt Sensor fixing - 3 pcs .;

7. Paper;

8. The fabric cover;

9. ECG cable;

10. Disposable ECG electrodes;

11. The cuff;

12. Extension of the cuff;

13. SpO2 sensor;

14. Breathing tube (disposable);

15. rectal temperature sensor;

16. Temperature Sensor epidermal;

17. Instructions;

18. Warranty Card;

19. A copy of the registration certificate of the Ministry of Health of Ukraine;

20. A copy of the Certificate of Compliance UkrSEPRO.

Attributes fetal monitor

Display 12.1 "TFT

Thermal Yes

Paper, 152 mm

FHR Yes

HR 2nd fetal Option

The tone of the uterus Yes

The movement of the fetus Yes

Event Marker Yes

Archive data Yes

Automatic analysis Fischer Yes

Control of the mother: HR, SPO2, BP No

Control of the mother: HR, SPO2, BP, temperature, respiratory rate, ECG Yes

Yes Built-in battery

Warranty 18 months

Air Sterilizers GP-40

 for air sterilization of surgical instruments, heat-resistant syringes and needles (marked + 200 deg. C), as well as glassware, other health facilities.

Main advantages:

-high level of automation;

be an optimal forced circulation of hot air in the chamber a high-quality engine;

-Quantitative insulation;

-sterilizatsionnaya camera and boot box are made of polished, heat-resistant, stainless steel;

-high informativeness of the control panel, which provides a digital readout of the current temperature and time, light indication of the main stages of the cycle;

-predusmotreny locks in excess of the temperature deviation and emergency stop.

Specifications

The chamber volume, l 40

The dimensions of the sterilization chamber, mm WxHxD 285h470h300

Supported operating modes, hail. C / min Mode 1 - Mode 2 85/30 - 120/45 Mode 3 - 160/150 Mode 4 - 180/60 Mode 5 - 50 ... 200

Temperature deviation in terms of the sterilization chamber, degrees C + (-) 3

Supply voltage, V 220

Time of heating to a sterilization temperature, 25+ min (-) 5

Maximum power consumption, kW 1,5

Overall dimensions (sh.v.g.) 580h595h445

Average service life, years 8

sterilizer Weight, kg 30

Number of loading boxes 4 pcs

Steam Sterilizer GK-20 with vacuum drying

with automatic control of all phases of the sterilization cycle (hereinafter sterilizer) are designed to automatically provide steam sterilization in accordance with OST 42-21-2-85 medical devices made of metal (surgical, dental instrument) of heat-resistant rubber; glass (syringes, glassware) and textiles (bandages, sutures and others.) both unpackaged and packaged in special packages in a synthetic film and paper.

Main advantages:

-automatic control;

-sterilizatsionnaya camera and boot box are made of polished, heat-resistant, stainless steel;

-Quantitative insulation;

-high informativeness of the control panel, which provides a digital readout of the current temperature and time, light indication of the main stages of the cycle;

-control the current pressure values ​​is carried out on the door built-in pressure gauge;

-system reusable water by its return to the form of steam through the nozzle throughout the cycle, followed by condensation in the water tank;

- Dosed supply of water to the steam chamber, ensuring a minimum percentage of moisture sterilization facilities when removed from the camera

Table programs and sterilization cycles hollow, porous and packaged medical products using the method of vacuum drying

Name

program 3

program 5

program 6

program 7

Sterilization temperature ° C

121 ±

126 ±

132 ±

134 ±

Pressure MPa; kgf / cm²

0,11 (1,1) ± 0,01 (± 0,1)

0,14 (1,4) ± 0,01 (± 0,1)

0,2 (2,0) ± 0,01 (± 0,1)

0,21 (2,1) ± 0,01 (± 0,1)

sterilization holding time min.

20 (2)

10 (1)

20 (1)

 5 (1)

Installation of the program, monitoring water in the tank, the removal of the residual vacuum

+

+

+

+

air Pumping

+

+

+

+

Condensate drain from the drier

+

+

+

+

Heating to 125 ° C

+

+

+

+

Discharge pressure until a temperature of 105 ° C

+

+

+

+

Heating up to the set temperature

+

+

+

+

Sterilization exposure

+

+

+

+

Pressure relief in three stages until a temperature of 120 ° C, 116 ° C, 106 ° C

+

+

+

+

Vacuum drying

+

+

+

+

Pressure equalization to atmospheric pressure in the chamber

+

+

+

+

Unloading

+

+

+

+

Dry-air thermostat TS-80

for obtaining and maintaining a highly stable inside the cooking chamber temperature required for bacteriological and serological studies in the clinical diagnostic and sanitary-bacteriological laboratories, clinics, hospitals, research institutes, laboratories, food industry and others.

The result is high-quality work is achieved through:

-Automatic regulation and maintenance of the desired temperature;

-continuous digital display the current temperature;

-prinuditelnoy air circulation in the chamber;

-zerkalnoy stainless steel used for the manufacture of the working chamber;

-Additional transparent doors

Specifications

The volume chamber 80 l

The dimensions of the sterilization chamber, mm WxHxD 400h550h360

Supply voltage, V 220

Maximum power consumption, kW 0,6

Overall dimensions (sh.v.g.) 520h760h600

Average service life, years 8

sterilizer Weight, kg 45

Number of loading boxes, 3 pcs

specifications thermostats

range adjustable temperature degrees C Tamb. + 5 ... 60

Setpoint temperature 0.1 degrees C

accuracy of temperature at the reference point + (-) 0.4

limiting the temperature deviation with respect to a reference point + (-) 1

More transparent door there

CHS-E1000 - is a gynecological chair of the highest quality that takes many excellent features and is equipped with modern electro-hydraulic pump. Designed to be easy and comfortable, for both physician and patient to conduct the survey. It can be used for inspection of pregnant women or patients with gynecological diseases.

Features:

The product gives maximum support and comfort for the patient, as it is intended to achieve the most optimal position for examination. In addition, the appearance of the product, designed by professional designers, looks elegant and carefully so that the patient did not feel a sense of psychological discomfort.

Easy-to-use wireless remote control as a foot pedal provides a comfortable change of the seat position. You can move back and seat up / down free touch switches.

The chair moves with the lowest possible noise level, just maintains its position.

The entire area chipped a soft coating that is not susceptible to corrosion when exposed to moisture or other chemicals and has a long service life.

Compact size chair can comfortably put it in a small doctor's office. The length of the maximum lowered backrest is 1.27 cm and width - 65 cm.

The seat can be raised to a height of 48 cm to 1 m.

Built-in memory schemes allow to go to the previously stored position with one touch, so that the examinee can take the most comfortable position immediately without any inconvenience.

Excellent opportunity fractional movement lets you move a chair by fractional simple operation.

Simple-to-use accessories (support for the shoulder and the additional section for the legs) can be easily attached to the table.

Integrated display reflects the height and angle.

STANDARD SET OF ACCESSORIES:

Support for the knee - 2 pcs.

Banks tools and wool with fastening - 2 pieces.

Foot switch

anesthesia frame

Roll of water resistant paper

Waste tray

Armrest - 2 pcs.

OPTIONAL ACCESSORIES:

Additional section for feet

Shoulder Support (pair)

Attributes of the operating table

Overall length 1270 mm

Width 650 mm

Height 480 -1015 mm

The angle (up) back holder 50 °

The angle (down) the back of the holder 5 °

Adjusting the height of the provisions of the bed and footrest, the slopes of the spinal section and foot section, synchronous tilts the bed by means of a 4-electric LINAK (Denmark).

Tilt the head to the section and multi-control armrest is carried out manually. The wheels provide easy moving and adjustable support legs provide reliable stability of the chair. The chair is equipped with a multimedia stand.

parameters

meaning

Overall dimensions of the bed (L × W)

1700 ± 15 mm × 560 ± 15mm

The height of the chair

lowest 600 ± 15mm, the highest 830 ± 15mm

The inclination of the head section to

18 ° - 28 °

The slope of the back section

-10 ° - 65 °

Tilting foot section

-60º - 8º

Rotate the armrest toward

0º - 45º

The range of movement of the armrest

100 mm

Armrest height adjustment range

100 mm

Offset footrest

100 mm

The slope of the footrest

0º - 90º

permissible load

160 kg.

weight 130 kg

Stomatological installation of the upper middle class has electromechanical chair; upper or lower supply of tools; 3 four-channel turbine hose (Midwest); water gun / air. The main characteristics of the installation:

Doctor Unit:

- Block the doctor with the possible deployment of 6 instruments on the lower pitch and 5 instruments on top.

- Pnevmofiksatsiya medical unit

- Membrane control panel on the dentist unit with the possibility of programming, X-ray viewer,

- 3 four-channel turbine hose. (Midwest)

- Exit at pnevmomikromotor,

- Instrumkntalny table made of stainless steel.

- Three-functional water gun / air,

- The system with clean water tank.

The assistant unit:

- Saliva ejector and ezhektronogo type vacuum cleaner,

- 3-gun functional water / air

- Ceramic rotary spittoon, electronic control of cup filling and flushing of the spittoon, water heater

- Wide comfortable individually programmable electromechanical chair with two preset programs (Trendelenburg position, zero position)

- Seamless coverage (mechanical and chemical resistance)

- Anatomically shaped, ergonomic design

- Two metal armrest (right to control "on the knee")

- Seat control unit doctor, The assistant control panel and multi-function pedal.

- Founding chair - durable Rezinoplast.

- Diode shadowless lamp with touch controls and a smooth brightness control.
